Description
Work cycle : 8h
PDP : -20 ℃ , -40 ℃
Rated condition:
Working pressure : 0.7Mpa
Inlet temperature : 120 ℃
PDP : -40℃ (for screw compressor) -20℃ (for centrifugal compressor)
Cooling water temperature : 32 ℃
Other :For high pressure type ≥ 1.0Mpa and high inlet temperature type > 140 ℃ can be customized
Add additional heating device = With heater assists
Technical Data
Equipemd with oil free screw compressor
related inlet pressure: 7 barg, inlet temperature 180°C-200°C, cooling water temperature 32°C, dew point -40°C
| Model |
Air
Connection |
Cooling |
Capacity |
Cooling water consuption |
Absorbed
Power (kW) |
Dimension mm |
Weight |
| water |
| Connection |
m³/min |
t/h |
L |
W |
H |
kg |
| ENXY-60ZP |
DN50 |
DN50 |
6 |
7.6 |
0.25 |
2000 |
1055 |
2106 |
1200 |
| ENXY-80ZP |
DN50 |
DN50 |
8 |
10.3 |
0.25 |
2000 |
1055 |
2106 |
1250 |
| ENXY-100ZP |
DN50 |
DN50 |
10 |
12.8 |
0.25 |
2050 |
1099 |
2323 |
1675 |
| ENXY-120ZP |
DN50 |
DN50 |
12 |
15.3 |
0.25 |
2050 |
1099 |
2323 |
1725 |
| ENXY-150ZP |
DN50 |
DN65 |
15 |
19.1 |
0.25 |
2100 |
1100 |
2397 |
1800 |
| ENXY-200ZP |
DN65 |
DN65 |
20 |
25.5 |
0.25 |
2480 |
1250 |
2595 |
2375 |
| ENXY-220ZP |
DN65 |
DN65 |
22 |
28 |
0.25 |
2480 |
1250 |
2595 |
2425 |
| ENXY-250ZP |
DN65 |
DN65 |
25 |
31.9 |
0.25 |
2480 |
1250 |
2595 |
2500 |
| ENXY-350ZP |
DN80 |
DN65 |
35 |
44.6 |
0.25 |
2600 |
1300 |
2661 |
2950 |
| ENXY-450ZP |
DN100 |
DN65 |
45 |
57.4 |
0.25 |
2700 |
1500 |
2667 |
3450 |
| ENXY-500ZP |
DN100 |
DN65 |
50 |
63.8 |
0.25 |
2700 |
1500 |
2667 |
3600 |
| ENXY-600ZP |
DN100 |
DN65 |
60 |
76.5 |
0.25 |
2850 |
1500 |
2680 |
4000 |
Equipemd with centrifugal compressor
related inlet pressure: 7 barg, inlet temperature >110°C, cooling water temperature 32°C, dew point -20°C
| Model |
Air
Connection |
Cooling |
Capacity |
Cooling water consuption |
Absorbed
Power (kW) |
Dimension mm |
Weight |
| water |
| Connection |
m³/min |
t/h |
|
L |
W |
H |
kg |
| ENXY-700ZP |
DN125 |
DN65 |
70 |
41 |
0.25 |
3550 |
1850 |
2839 |
4250 |
| ENXY-800ZP |
DN125 |
DN65 |
80 |
47 |
0.25 |
3550 |
1850 |
2839 |
5200 |
| ENXY-900ZP |
DN150 |
DN80 |
90 |
53 |
0.25 |
3950 |
2050 |
2990 |
6900 |
| ENXY-1000ZP |
DN150 |
DN80 |
100 |
59 |
0.25 |
3950 |
2050 |
2990 |
7500 |
| ENXY-1200ZP |
DN150 |
DN80 |
120 |
71 |
0.25 |
3950 |
2050 |
2990 |
8150 |
| ENXY-1500ZP |
DN200 |
DN80 |
150 |
88 |
0.25 |
4700 |
2400 |
2905 |
9850 |
| ENXY-1800ZP |
DN200 |
DN125 |
180 |
106.5 |
0.25 |
4900 |
2600 |
3025 |
11800 |
| ENXY-2000ZP |
DN200 |
DN125 |
200 |
118 |
0.25 |
4900 |
2600 |
3025 |
13300 |
| ENXY-2500ZP |
DN200 |
DN125 |
250 |
147 |
0.25 |
5400 |
2800 |
3135 |
15575 |
| ENXY-3000ZP |
DN250 |
DN150 |
300 |
176 |
0.25 |
5800 |
3000 |
3400 |
18700 |
| ENXY-3500ZP |
DN250 |
DN150 |
350 |
206 |
0.25 |
5810 |
3038 |
3348 |
19970 |
| ENXY-4000ZP |
DN300 |
DN150 |
400 |
235 |
0.25 |
6321 |
3410 |
3822 |
21220 |
| ENXY-5000ZP |
DN400 |
|
500 |
|
| ENXY-6000ZP |
DN400 |
|
600 |
