Description
|
standard work codition：Standard atmospheric pressure: 1atm, ambient temperature: ≤ 40 ℃, relative atmospheric humidity: 50%, parameter table below Codice standard del lavoro: Pressione atmosferica standard: 1atm, temperatura ambiente: ≤ 40 ℃, umidità atmosferica relativa: 50%, tabella dei parametri qui sotto |
|||||||
|
Model |
Rated power(kw) |
rotation speed(rpm) |
FAD rate (m³/min) |
Exhaust pressure(barg) |
cooling way |
demension（mm） |
weight(kg) |
|
EBWLGI-1/16-15 |
15 |
3000 |
1.0 |
16 |
Air |
1550*1350*1450 |
900 |
|
EBWLGI-1.5/16-22 |
22 |
3000 |
1.6 |
16 |
Air |
1850*1500*1900 |
1200 |
|
EBLGI-3/16-37 |
37 |
3000 |
3.0 |
16 |
Air |
3100*1850*2150 |
1800 |
|
EBWLGII-2/20-18.5 |
18.5 |
3000 |
2.0 |
20 |
Air |
1850*1500*1900 |
1200 |
|
EBWLGII-3/20-30 |
30 |
3000 |
3 |
20 |
Air |
3100*1850*2150 |
1650 |
* Supports heterogeneous voltage and frequency, explosion-proof design, mobile design, high cold, high heat, plateau, and high dust environment design, special gas compression design, preheating utilization design, gas heating design, special space limitations and special requirements design, and exhaust pressure design<4.0MPA.
